Platform Architecture
Platform Architecture
shows the internal captive screws in the rear of the shelf that are used to lock
Figure 1-3
the two ATCA-F140-D fabric switch blades to the backplane. The AXP1440-C07 has been
tested to work with the ATCA-F140-D switch fabric blades, providing Ethernet switching
and communication between all of the application and payload blades in the system.Two
screws in the rear of the shelf are fastened to the specialized locking attachment block on
the ATCA-F140-D blade.

Figure 1-3 Captive Screws to Lock ATCA-F140-D Blades

Internal Captive Screws
