Figure 1-4
fastening to the ATCA-F140-D blade. There are specialized locking attachment blocks on
the ATCA-F140-D blade and on the RTM-ATCA-F140-D blade. See
The top ejector handle on the RTM-ATCA-F140-D is not same as the bottom ejector
handle. This is to allow room for the long captive screws.

Figure 1-4 Long Captive Screw Protruding from the RTM-ATCA-F140-D

AXP1440-C07 Installation and Use (6806800V18A)
shows the long captive screw protruding from the RTM-ATCA-F140-D and
Platform Architecture
Figure 1-5 on page
56.
55
