Matrix 832 / 832+ / 424

6.2 The LCD Keypad

Illuminated
Blinking
Extinguished
Illuminated
Blinking
Extinguished
Illuminated
Blinking
Extinguished

6.3 The Proximity Reader

Supply
Illuminated
Supply
Blinking
Extinguished
Illuminated
Status
Blinking
LEDs
Extinguished
Page 22
Rest of the World
Correct AC & DC power sources
Indicates DC source (battery) fault
Indicates AC fault / no power to panel
OK to Arm, no open zones
Select partitions to arm or disarm / Programming function is active
One or more open zones or all assigned partitions are already armed
Indicates a system Fault
Engineer Mode active
No Fault active
Status LEDs
Correct AC & DC power sources
Indicates DC source (battery) fault
Indicates AC fault / no power to panel
Partition or Arm mode is Armed
Partition or Arm mode is in Alarm
Partition or Arm mode is Disarmed
Denmark, Norway, Finland & Sweden
AC power is OK
Indicates an AC fault
No power to the panel
Multipartition Single Partition
Partition 4 Arm mode D
Partition 3 Arm mode C
Partition 2 Arm mode B
Partition 1 Arm mode A
