Pyronix Matrix Series Installation Manual page 8

Matrix 832 / 832+ / 424
FUSES
Bell fuse
Aux fuse
Keypad fuse
Battery fuse
BATTERY
Type
Battery Charge
Maximum Battery Charge
Current
Battery Charge Method
Battery Capacity
BAT Terminal Protection
Low Battery Detect Level
Battery Cutoff Level
MECHNICAL
Security Grade
Environmental Class
Dimensions
Plastic
Metal
TEMPERATURE
Operational
Storage
Maximum Humidity
Page 2
Matrix 832+
Quick blow 1A – F1L
Quick blow 1A – F1L
Quick blow 1A – F1L
Slow blow 5A – T5H
12V Lead acid
rechargeable
Min 6V
800mA (Metal Case)
350mA (Plastic case)
The Matrix panel monitors the voltage of the battery and commences
charging when the battery reaches 12.8V +/- 5% and disables charging
when it reaches 13.6V +/- 5%.
Metal Enclosure
2.8 to 17Ah
Plastic Enclosure
2.8 to 7Ah
Short circuit & battery
reverse protection.
10.7V +/- 0.2V
10.4V +/- 0.2V
(With MX-BATT)
2 (Metal Case)
N/A (Plastic Case)
2 (Metal Case)
N/A (Plastic Case)
340 x 280 x 94.5 mm
389.5 x 314.5
96.2mm
Metal Case
-10 to +55ºC
14 to 131ºF
Plastic Case
0 to +40ºC
32 to 104ºF
-20 to +60ºC
-4 to 172ºF
93% Rh (Metal Case)
Matrix 832
Quick blow 1A – F1L
Quick blow 1A – F1L
N/A
N/A
12V Lead acid
rechargeable
Min 6V
350mA
Plastic Enclosure
2.8 to 7Ah
Short circuit & battery
reverse protection.
10.7V +/- 0.2V
10.4V +/- 0.2V
(With MX-BATT)
N/A
N/A
340 x 280 x 94.5 mm
x N/A
0 to +40ºC
32 to 104ºF
-20 to +60ºC
-4 to 172ºF
N/A
Matrix 424
Quick blow 1A – F1L
N/A
N/A
N/A
12V Lead acid
rechargeable
Min 6V
350mA
Plastic Enclosure
2.8 to 7Ah
Short circuit & battery
reverse protection.
10.7V +/- 0.2V
10.4V +/- 0.2V
(With MX-BATT)
N/A
N/A
340 x 280 x 94.5 mm
N/A
0 to +40ºC
32 to 104ºF
-20 to +60ºC
-4 to 172ºF
N/A
RINS428-5
