Pyronix Matrix Series Installation Manual page 14

Matrix 832 / 832+ / 424
CENTRAL MONITORING OPTIONS – Cont.
Group Reporting to CMS
Programmable Send
Options
Test Call
Telephone Line Monitoring
Telephone Connection
Digital Communicator
Lightning Protection
OTHER
Software Support
Memory Event Log
1.3.1.1 Minimum Installation Requirements
In addition to the main alarm panel (424, 832 or 832+), and any detectors or sensors, at least one keypad is
required. This can be an LCD, LED or ICON keypad. One keypad MUST be set to ID-1. This is the minimum
requirement.
1.3.1.2 Installation Constraints
A maximum of 6 devices can be attached to the Matrix bus (see also Section 4: Cabling Rules for the Matrix
Bus). The following table shows the maximum number of each device type allowable, whilst at the same time
remembering that only 6 devices in total can be on the bus at any one time.
BUS DEVICE
LCD Keypad
ICON Keypad
MX-PROX Proximity Reader
MX-RIX with Zone Analyser
On-board Input Expander
MX-ROX Output Expander
Page 8
1. Events sent to 1 number only
2. Events sent to 2 numbers
3. Events sent to first number with
backup of second number
1. In disarmed mode
2. In arm modes A, B, C and D
3. Restorals
4. Alarms
5. PAs
6. Fire
7. Maintenance
8. Open / Close
9. Medical
Programmable in days, hours and
minutes
Yes – with status indication
Allows other telephone on the line
Analogue line
Heavy duty lightning
6.75kV/125Amps
1. UDL programming software
2. Pyronix MX-MON software to be
used with:
a. Modem + Pyronix format
b. RC12/RC112 +
Contact ID/BSIA
300 events with time and date
Log deletion cannot be allowed either
accidentally or on purpose.
Log reaction time is more than 30
days and the clock will not change
more than + / - 10 mins over 1 year at
20c
MATRIX 832+ /832
4
4
4
1
1
1
1. Events sent to 1 number only
2. Events sent to 2 numbers
3. Events sent to first number with
backup of second number
1. In disarmed mode
2. In arm modes A, B, C and D
3. Restorals
4. Alarms
5. PAs
6. Fire
7. Maintenance
8. Open / Close
9. Medical
Programmable in days, hours and
minutes
Yes – with status indication
Allows other telephone on the line
Analogue line
protection Heavy
6.75kV/125Amps
1. UDL programming software
2. Pyronix MX-MON software to be
used with:
a. Modem + Pyronix format
b. RC12/RC112 +
300 events with time and date
Log deletion cannot be allowed either
accidentally or on purpose.
Log reaction time is more than 30
days and the clock will not change
more than + / - 10 mins over 1 year at
20c
MATRIX 424
4
4
4
1
1
1
duty lightning protection
Contact ID/BSIA
RINS428-5
