Matrix 832 / 832+ / 424

12.12.10 Vocaliser Connection to Matrix 832+

Bell Fuse 1Amp
+BELL-
+
BAT
17V AC
Output
IMPORTANT
See Vocaliser User guide for complete
Vocaliser programming options.
In this instance programmable
outputs are programmed as follows
PGM1 = "External Bell"
PGM2 = "Follow PA"
PGM3 = "Follow Fire"
PGM4 = C+ (if Abort function is required)
Page 156
Aux fuse 1Amp Keypad fuse 1 Amp
-
B
with 4 programmable outputs
+AUX-
A
T T
Vocaliser Connections
1
4 3 2
RINS428-5
