Pyronix Matrix Series Installation Manual page 12

Matrix 832 / 832+ / 424
PGM Options
PGM Expander MX-ROX
Outputs
KEYPADS
Type
Dedicated buttons
Max number
Settings
LCD Keypad
Supply Voltage
Supply Current
LED Keypad
Supply Voltage
Supply Current
ICON Keypad
Supply Voltage
Supply Current
Page 6
Matrix 832 / 832+
1. Off
2. PIR remote LED enable (E-)
3. PIR Latch memory (C+)
4. Follow Arm / Disarm
5. Follow zone
6. Follow line fail
7. Follow kiss off
8. Shock / Fire reset
9. Follow strobe
10. Follow Fire Alarm
11. Follow PA
12. Confirmed Alarm
13. Follow Tamper Alarm
14. External Bell
15. GND Fire detector – PGM 4 only
16. Twin Alert – PGM 3 only
17. Follow entry exit
18. Follow Digi Com - Fire Signal
19. Follow Digi Com - PA Signal
20. Follow Digi Com - Intruder Signal
21. Follow Digi Com - Open/Close
22. Follow Digi Com - Spare Signal
23. Follow Digi Com - Medical Signal
24. Follow Digi Com - Conf Signal
25. Follow Digi Com - Omits Signal
26. Follow Hidden Display
27. Follow Mains Fail
28. Follow Battery Low
29. Follow Battery Missing
30. Internal Sounder
1. 8 open collector – Installable
remotely on keypad bus
2. 8 relay expander – installable
remotely on keypad bus
1. Two 7 segments LED
2. LCD 32 character
3. ICON
1. PA
2. Fire
3. Medical
Four of same type (max 6 devices)
1. Private - system status indicated
during arming
2. Public - system status indicated
in arm mode
3. Hidden - display suppressed after
20 seconds
9-16Vdc
80mA – Normal
20mA – Minimum brightness setting
9-16Vdc
60mA Maximum @ 13.8V
9-16Vdc
50mA Maximum @ 13.8V
Matrix 424
1. Off
2. PIR remote LED enable (E-)
3. PIR Latch memory (C+)
4. Follow Arm / Disarm
5. Follow zone
6. Follow line fail
7. Follow kiss off
8. Shock / Fire reset
9. Follow strobe
10. Follow Fire Alarm
11. Follow PA
12. Confirmed Alarm
13. Follow Tamper Alarm
14. External Bell
15. GND Fire detector – PGM 4 only
16. Twin Alert – PGM 3 only
17. Follow entry exit
18. Follow Digi Com - Fire Signal
19. Follow Digi Com - PA Signal
20. Follow Digi Com - Intruder Signal
21. Follow Digi Com - Open/Close
22. Follow Digi Com - Spare Signal
23. Follow Digi Com - Medical Signal
24. Follow Digi Com - Conf Signal
25. Follow Digi Com - Omits Signal
26. Follow Hidden Display
27. Follow Mains Fail
28. Follow Battery Low
29. Follow Battery Missing
30. Internal Sounder
1. 8 open collector – Installable
remotely on keypad bus
2. 8 relay expander – installable
remotely on keypad bus
1. Two 7 segments LED
2. LCD 32 character
3. ICON
1. PA
2. Fire
3. Medical
Four of same type (max 6 devices)
1. Private - system status indicated
during arming
2. Public - system status indicated
in arm mode
3. Hidden - display suppressed after
20 seconds
9-16Vdc
80mA – Normal
20mA – Minimum brightness setting
9-16Vdc
60mA Maximum @ 13.8V
9-16Vdc
50mA Maximum @ 13.8V
RINS428-5
