Pyronix Matrix Series Installation Manual page 13

!
PROXIMITY READER (Not approved for use in Denmark, Norway, Finland or Sweden)
Type
Max number
Settings
Supply Voltage
Supply Current
PARTITIONS
Number of partitions
Independent settings
Arm modes
Home / Away allocation
Arming options
Timers
Real time clock
USER CODES
Number of user codes
User code types
CENTRAL MONITORING OPTIONS
Telephone Numbers
Communication Protocols
RINS428-5
Matrix 832 / 832+
Inductively coupled key-fob or card
Four of same type (max 6 devices)
1. Private – system status indicated
during arming
2. Public – system status indicated
in arm mode
9-16Vdc
Max 90mA@13.8V
4 true partitions with common option
1. Zones
2. Keypads
3. Proximity readers
4. User codes
5. PGMs
6. Timers
7. Reporting account codes
4 arm modes per partition (A, B, C, D)
Programmable individual arm modes
1. Final door
2. Timed exit
3. Silent arm
4. Forced Arm
1. Entry / Exit
2. Bell Delay
3. AC Fault Delay
4. Telephone Line Fault Delay
5. Inactivity Arm Time 10-990min
6. Auto Arm – Time of Day
7. Final Exit Delay
8. Quartz Correction Factor
9. Confirmed Alarm
1. AC frequency Based
2. Quartz Based
32 codes (4 to 6 digits)
1. Master user per partition
2. Limited user
3. Duress
4. Engineer
5. Arm only - can be used as a
patrol code
6. Disarm only - can be used as a
patrol code
7. Omit (Bypass)
8. Temporary
9. Limited number of uses
9 telephone numbers shared with
pager, Pyronix PC format and digital
communication formats
1. Contact ID
2. Pager Format
3. BSIA Fast Format
4. Pyronix PC Format
5. MX Voice
Matrix 832 / 832+ / 424
Matrix 424
Inductively coupled key-fob or card
Four of same type (max 6 devices)
1. Private – system status indicated
during arming
2. Public – system status indicated
in arm mode
9-16Vdc
Max 90mA@13.8V
4 true partitions with common option
1. Zones
2. Keypads
3. Proximity readers
4. User codes
5. PGMs
6. Timers
7. Reporting account codes
4 arm modes per partition (A, B, C, D)
Programmable individual arm modes
1. Final door
2. Timed exit
3. Silent arm
4. Forced Arm
1. Entry / Exit
2. Bell Delay
3. AC Fault Delay
4. Telephone Line Fault Delay
5. Inactivity Arm Time 10-990min
6. Auto Arm – Time of Day
7. Final Exit Delay
8. Quartz Correction Factor
9. Confirmed Alarm
1. AC Frequency Based
2. Quartz Based
32 codes (4 to 6 digits)
1. Master user per partition
2. Limited user
3. Duress
4. Engineer
5. Arm only - can be used as a
patrol code
6. Disarm only - can be used as a
patrol code
7. Omit (Bypass)
8. Temporary
9. Limited number of uses
9 telephone numbers shared with
pager, Pyronix PC format and digital
communication formats
1. Contact ID
2. Pager Format
3. BSIA Fast Format
4. Pyronix PC Format
5. MX Voice
Page 7
