8.15.5 LOAD BYTE (LB)
Function
Load inputs I3 to I10 into the
accumulator (bit 0 to bit 7).
Assign accumulator contents to
byte 8.
8.15.6 LOAD WORD (LW)
January 2012
Syntax: LB (LOAD BYTE)
Operands: M, I, O, T, C
Action:
Copy 8 markers, inputs, outputs, timers or counters with ascending
numbering into the word accumulator. Each operand occupies one bit in the
accumulator. The control saves the given operand address as LSB in the
accumulator, the given address + 1 as LSB + 1 and so on. The last (8th)
operand becomes the MSB! If necessary, the control fills the accumulator
with the correct algebraic sign.
Example:
A pure-binary coded value is read through inputs I3 to I10 and saved in byte B8
in order to process it later.
Initial state:
Input I3 = 1
Input I4 = 1
Input I5 = 1
Input I6 = 0
STL Accumulator
content
7 6 5 4 3 2 1 0 I10 I9
LB I3 1 1 1 0 0 1 1 0 0
= B8 1 1 1 0 0 1 1 0 1
Syntax: LW (LOAD WORD)
Operands: M, I, O, T, C
Action:
Copy 16 markers, inputs, outputs, timer or counters with ascending
numbering into the word accumulator. Each operand occupies one bit in the
accumulator. The control saves the given operand address as LSB in the
accumulator, the given address + 1 as LSB + 1 and so on. The last (16th)
operand becomes the MSB! If necessary, the control fills the accumulator
with the correct algebraic sign.
Example:
See example command LB. Use command LW in the same way as LB.
However, the control processes 16 operands.
8.15 Command Set
Input I7 = 0
Input I8 = 1
Input I9 = 1
Input I10 = 0
Operand content
I8 I7 I6
1 1 0 0
7 6 5 4 3
1 1 0 0
I5 I4 I3
1 1 1
2 1 0
1 1 0
