Technical data

LaserHybrid Ul-
Weight (without laser optics system)
tracompact Twin
Laser optics
(laser welding
head)
Duty cycle of the laser optics
Dimensions
Max. laser power on the workpiece
Max. current capacity of the welding torch
(100% D.C.)
* corresponds to 36 s of welding, 24 s pause
LaserHybrid Ul-
Max. welding current at 100% D.C. (10 min / 40 °C)
tracompact Twin
M21 (EN439)
hosepack
C1 (EN439)
Wire diameter
Voltage measurement (V-Peak)
Hosepack length
Cooling system
Coolant
Lowest cooling capacity in accordance with IEC 60974-2,
depending on the length of the hosepack
Min./max. coolant pressure
Min. coolant flow
The product conforms to the requirements of the IEC 60974-7 standard.
Trumpf BEO D35 / F300
100% at 4 kW and per minute
*60% at 6 kW and per minute
360 x 150 x 610 mm
6000 W
2 x 300 A
2 x 300 A
2 x 300 A
1.0 - 1.6 mm
141 V
7.5 m
Liquid cooling
Original Fronius coolant
1800 W
3.0 / 5.5 bar
1.0 l/min
8 kg
