Mounting Positions For Installing The Laser Optics System - Fronius LaserHybrid Ultracompact Twin Operating Instructions Manual

Table of Contents

(16)

(17)

(18)

Mounting posi-

tions for install-

ing the laser

optics system

(A)

(B)

1 4

Mounting position for laser optics system with camera module

Mounting position for laser optics system without camera module

Remove the two Allen screws (16) and

(17)

(3 mm)

(17)

Undo the two Allen screws (17) and

(18)

(3 mm)

Remove the laser optics system by

pulling it upwards

(A)

(B)

e.g. laser optics system with camera module (1)

(without camera)

(1)
