Description of the device

Description of the
device
*
(17)
(3a)
Item
(1)
(2)
(3)
(3a)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(1)
(2)
(3)
(4)
(5)
Designation
Crossjet outlet air connection
Protective cover/fibre optic cable connection
Additional extractor
Optional additional extractor (with corresponding spatter guard sheet)
One of the two extractors is fitted prior to delivery depending on the configuration.
Laser optics
Radial air flow
Gas nozzle
LaserHybrid Ultracompact Twin welding torch
Adjusting device
Drive roller cover
Motor cover
Robot connection flange
