Threading the wire electrode

Preparatory work

Removing the
1
1
welding torch
wearing parts
Remove the gas nozzle
(2.5 mm Allen key)
58
1
1
2
3
Remove the two Allen screws
1
(4 mm)
Remove the media cover
2
Remove the Allen screw
3
(3 mm)
Remove the Allen screw on the oppo-
4
site side
(3 mm)
Pull the drive roller cover towards the
5
rear and remove it
4
2
2
Unscrew the contact tips
(7 mm flat spanner)
