Compressed Air Diagram - Fronius LaserHybrid Ultracompact Twin Operating Instructions Manual

Item
(5)
(6)
(7)
Compressed air
diagram
40
Designation
Laser optics system water cooling connection
(of LaserHybrid interconnecting hosepack)
External wirefeeding hose (Fronius)
LaserHybrid interconnecting hosepack (Fronius)
Hosepack incl. compressed air for Crossjet and radial air flow, water cooling for
laser optics system and media coupling
(4)
(4)
(5)
(2)
(3)
(2)
Item Designation
(1) Compressor supply
(min. 6 bar)
(2) Crossjet inlet air connection
(3) Radial air flow branch connection
(4) Crossjet outlet air
(5) Extractor
(3)
(1)
1000 l/min
