Removing the la-
Note:
ser optics system
The numbering of the arrows in the illustrations may differ from the work steps.
98
1
1
2
1
Remove the two Allen screws
1
(4 mm)
Remove the media cover
2
Remove the two Allen screws
3
(3 mm)
Push the spatter guard plate back-
4
wards and remove it
1
Unscrew the extraction pipe
5
(28 mm)
5
