Connect the hose and adapter from the
4
laser welding head scope of supply
Connect the hose
5
Fit the flow rate meter to the hose and
6
adapter
Check whether the Crossjet supply
7
complies with the given specification
Switch on the Crossjet
8
Set the flow rate to 25 l/min using a
9
small slotted screwdriver
Remove the flow rate meter
10
Disconnect the hose and adapter
11
