Adjusting the y-
axis
Laser - lead wire electrode
Lead wire electrode - trail wire electrode
*
(1)
0 2 0 5 10
=
- 3 mm + 3 mm
(1)
determined by the welding torch geometry
NOTE! The y setting range of ± 3
mm starts from the second gradu-
ation mark on the y scale.
In position 0, both the laser and
wire electrode would fall on the
same exact location.
(1) Laser beam
Undo the grub screw (1)
1
(3 mm)
Use the adjusting screw (2) and the 3
2
mm Allen key to adjust the y-axis:
1 rotation corresponds to 1.0 mm
Once the y-axis has been adjusted, re-
(2)
3
tighten the grub screw (1)
Illustration of both adjusting devices without
covers
Standard distance values
3 - 5 mm
7 - 8 mm*
