Replacing wearing parts
Preparatory work
2
Removing the
feed rollers
* Fully open
1
1
3
Remove the two Allen screws
1
(4 mm)
Remove the media cover
2
Remove the Allen screw
3
(3 mm)
Remove the Allen screw on the oppo-
4
site side
(3 mm)
Pull the drive roller cover towards the
5
rear and remove it
4
Fully open the adjusting screw
1
83
