Connecting the
LaserHybrid Ul-
tracompact Twin
hosepack to the
laser welding
head
48
1
2
Remove the Allen screw
8
(3 mm)
Pull the motor cover towards the rear
9
and remove it
Feed in the hosepack
1
Push the hexagon nut over the media
2
Lightly tighten the hexagon nut
3
