LBC-4000 L-Band Up/Down Converter System
Installation and Startup
Feature
Description
1
Custom Rack Enclosure
2
LBC-4000 chassis
3
Standard Rack Shelving
4
Rack Enclosure Threaded Front Rail (typical)
5
Unit Front Panel
6
User-supplied Screws
Figure 3-2. Install the Unit into a Rack Enclosure
3–4
MN/LBC4000.IOM
Revision 5
