LBC-4000 L-Band Up/Down Converter System
Introduction
Item 7 – Power Connection (part of Power Supply module)
Use this Prime Power receptacle for connection to 90 to 125 VAC, or 205 to 240
VAC power sources.
• The standard AC (Alternating Current) unit features an IEC-60320 Type
C14 three-prong male connector for use with the provided IEC-60320
Type C13 (female) receptacle power cord for connection to 90 to 125 VAC,
or 205 to 240 VAC power sources.
• The optional DC (Direct Current) Filter Input Module input voltage is
48VDC nominal, -36 VDC minimum, -72VDC maximum.
Item 8 – 'J6 | RF OUT/IN' (part of IDU Up / Down Converter Module)
Use this Type 'N' female connector as either the 'CONV A' L-Band output signal
interface (with the Down Converter IDU installed) or the L-Band input signal
interface (with the Up Converter IDU installed).
Item 9 – 'J7 | IF IN/OUT' (part of IDU Up / Down Converter Module)
Use this BNC female connector as either the 'CONV A' downconverted IF input
signal (with the Down Converter IDU installed), or the upconverted IF output
signal (with the Up Converter IDU installed).
Item 10 – 'P1 | RELAY' Utility Connector
Use this DB-9F connector to access the Form C Alarms (relay closures).
Item 11 – 'J1 | COM1' Serial Management Utility Connector
Use this DB-9F EIA-485/232 connector for operation of the Serial remote control
interface.
Item 12 – Unit Ground Lug
Use this #10-32 stud as the command chassis ground.
CAUTION
PROPER GROUNDING PROTECTION IS REQUIRED. You must connect the
equipment to the protective earth connection at all times. Use this ground
stud during installation, configuration, and operation.
1–8
MN/LBC4000.IOM
Revision 5
