LBC-4000 L-Band Up/Down Converter System
Firmware Update
• To use Windows Command-line or Command Prompt, see Section
5.3.1.2.
After you confirm the firmware files are in the folder, proceed to Section 5.4 to
upload the firmware update to the LBC-4000.

5.3.1.1 Use Windows Desktop to View Folder Contents

From the Windows Desktop:
1. Double-left-click the Windows Explorer icon, and then double-left-click as
needed to locate, and then open, the "temp" folder (directory) created
earlier on the Windows Desktop.
2. Use the Browse window (Start > ...Run > Browse) to locate, and then
double-click to open, the "temp" folder.

5.3.1.2 Use Windows Command-line to View Folder Contents

From Command-line or Command Prompt:
1. Type "cd c:\temp" at the Windows Command-line prompt to change to
the temporary folder (directory) created earlier using Command-line.
2. Type "dir" to list the files extracted to the temporary folder from the
downloaded archive file.
5.4 Upload the Firmware Files and Update the
LBC-4000 Unit
5.4.1

Important Considerations

Before you proceed with the firmware update, make sure that:
• You connect the LBC-4000 '10/100 ETHERNET' port to a Windows-based
PC Ethernet port with a CAT5e Ethernet cable.
• Your PC is running a terminal emulation program for operation of the
LBC-4000 Telnet or serial interfaces.
• You have noted your LBC-4000 Management IP Address.
• Your PC is running a compatible Web browser for operation of the
LBC-4000 HTTP Interface.
5–11
MN/LBC4000.IOM
Revision 5
