LBC-4000 L-Band Up/Down Converter System
Appendix A
A.2 IDU Module Removal Procedure
Do these steps:
Step Task
Loosen the front panel thumbscrews
(by turning counterclockwise), and
1
drop the front panel to access the
IDU modules.
Use a Phillip's®-head screwdriver to
loosen (by turning
2 counterclockwise) the captive
machine screws holding the IDU
module in place.
