LBC-4000 L-Band Up/Down Converter System
Firmware Update

5.4.4.2 Reboot the Unit

5.4.4.2.1 Hard-reboot the Unit from the Rear Panel

Typical for either the standard AC unit or the optional DC unit:
1. From the unit rear panel, switch the power OFF, and then turn the power
back ON.
2. Verify the new firmware version has booted; for example, check the
firmware version displayed on the LBC-4000 front panel:
LBC-4000
VER X.X.X

5.4.4.2.2 Soft-reboot the Unit from the HTTP Interface

Do these steps from the HTTP Interface 'Config | Utility' page:
1. In the 'Perform Soft Reboot' section, click [Reboot Now]:
2. Wait while the LBC-4000 reboots with the Current Active Firmware
Image.
3. To load a second image, repeat the tasks described throughout Section
5.4.4.
The LBC-4000 is now operating with its latest firmware. The firmware update
process is complete.
