LBC-4000 L-Band Up/Down Converter System
Serial Interface Operation
8.3.7

CMM (Configure Mute Mode)

Command or Query. Use "CMM" to set or return the mute mode.
Controller-to-Target Arguments for
Instruction Code and Qualifier Command or
Response to
Command Query
CMM_y_xxx CMM_y_
Command Example: <0001/CMM_A_OFF{cr} (Unmutes Converter A)
8.3.8

CMS (Concise Maintenance Status)

Query only. Use "CMS" to return a summarized version of the maintenance
status.
Controller-to-Target Arguments for
Instruction Code and Qualifier Command or
Response to
Command Query
N/A CMS_ 85 bytes,
numeric
Description of Arguments
Query
Set or return in the form CMM_y_xxx where:
5 bytes,
y=A (Conv A) or B (Conv B)
alphabetic
xxx=ON (mute) or OFF (unmute)
Description of Arguments
Query
Returns status info in the form
"CMS_aaa.abbb.bccc.cddd.deee.efff.fggg.ghhh.hiii
.ijjj.jkkk.klll.lmmm.mnnn.nooo.oppp.pqqq.q{cr}{lf}"
where:
aaa.a=12 VDC supply #1 in volts
bbb.b=8 VDC supply #1 in volts
ccc.c=5 VDC supply #1 in volts
ddd.d=12 VDC supply #2 in volts
eee.e=8 VDC supply #2 in volts
fff.f= 5 VDC supply #2 in volts
ggg.g=Ref Osc tuning in volts
hhh.h=Converter A IFLO tuning in volts
iii.i= Converter A RFLO tuning in volts
jjj.j=Converter A Input Power in dBm (Reserved for
future use)
kkk.k=Converter A Output Power in dBm
(Reserved for future use)
lll.l= Converter A temperature in degrees C
mmm.m=Converter B IFLO tuning voltage in volts
nnn.n= Converter B RFLO tuning voltage in volts
ooo.o=Converter B Input Power in dBm (Reserved
for future use)
ppp.p=Converter B Output Power in dBm
(Reserved for future use)
qqq.q=Converter B temperature in degrees C
8–11
MN/LBC4000.IOM
Revision 5
Target-to-Controller
Response
Command Query
CMM_y_xxx CMM_y_xxx
Target-to-Controller
Response
Command Query
N/A CMS_a...q
