LBC-4000 L-Band Up/Down Converter System
Ethernet Interface Operation
MAC Address – The MAC Address is read-only. It is set at the factory to a
guaranteed unique address. It cannot be changed.
Click [Change IP Address]. Click [Reset] to revert to the previously assigned IP
Gateway and IP Address/Range,
System Account Access Information
Admin, Read/Write, and Read Only Names and Passwords:
The User name and Password can be any alphanumeric combination
with a maximum length of 10 characters. The factory defaults for these
names/passwords are:
• Admin
• Read/Write
• Read Only
SMTP Server – Specify the mail server IP address from where you want to send
the e-mail.
SMTP Domain Name / Destination – The Administrator can assign the SMTP
Domain Name and Destination. This is required if the e-mail feature of the
'Home | Support' page (Sect. 7.5.1.3) is to be used.
• For SMTP Domain Name, specify the domain of the e-mail server (usually
found to the right of the @ symbol in an e-mail address).
• For SMTP Domain Destination, specify the e-mail recipient name (usually
found to the left of the @ symbol in an e-mail address).
Click [Submit Access]. Click [Reset] to revert to the previously assigned System
Account Access Information.
Webpage Timeout
To set an automatic timeout to safeguard access to an already logged-in unit, use
the drop-down list to set the time value as 5 minutes or 8 hours, and then click
[Change].
The active session terminates if the unit remains idle (i.e., when no user activity
occurs) beyond the assigned Webpage Timeout. A valid user name and password
is then required to resume the HTTP Interface session.
comtech/comtech
opcenter/1234
monitor/1234
7–15
MN/LBC4000.IOM
Revision 5
