LBC-4000 L-Band Up/Down Converter System
Specifications

2.1.8.2 RF Connectors Access

• Standard (part of Up or Down Converter IDU Module):
o (1X) 'J4 | RF OUT/IN' Type 'N' female connector provided for
either the 'CONV B' L-Band output signal interface (with the Down
Converter IDU installed) or the L-Band input signal interface (with
the Up Converter IDU installed).
o (1X) 'J6 | RF OUT/IN' Type 'N' female connector provided for
either the 'CONV A' L-Band output signal interface (with the Down
Converter IDU installed) or the L-Band input signal interface (with
the Up Converter IDU installed).
• Optional:
(2X) Type 'SMA' female 'RF Primary A / Secondary B' connector pairs (4X
total) provide the RF "baseball" switch for optional redundant
operations.

2.1.8.3 IF Connectors Access

• Standard (part of Up or Down Converter IDU Module):
o (1X) 'J5 | IF IN/OUT' BNC female connector serves as either the
'CONV B' downconverted IF input signal (with the Down Converter
IDU installed), or the upconverted IF output signal (with the Up
Converter IDU installed).
o (1X) 'J7 | IF IN/OUT' BNC female connector serves as either the
'CONV A' downconverted IF input signal (with the Down Converter
IDU installed), or the upconverted IF output signal (with the Up
Converter IDU installed).
• Optional:
(2X) BNC female 'IF Primary A / Secondary B' connector pairs (4X total)
provide the IF "baseball" switch for optional redundant operations.

2.1.8.4 Ethernet Connector

(1X) 100BaseTX RJ-45 female '10/100 Ethernet' Management Utility Port for
operation of the Ethernet remote control interfaces (SNMP, Telnet, HTTP).
