Chapter 2. Specifications; Physical And Environmental Specifications; Regulatory Compliance; Physical Specifications - Comtech EF Data MN/LBC4000.IOM Installation And Operation Manual

Chapter 2. SPECIFICATIONS

2.1 Physical and Environmental Specifications

2.1.1

Regulatory Compliance

• "CE" as follows:
o EN 50082-1 (EMC/Generic Immunity)
o EN 55022 Class B (Emissions)
o EN 55024 (Immunity)
o EN 60950 (Safety)
• FCC Part 15 Subpart B
• RoHS-Compliant
2.1.2

Physical Specifications

• Dimensions: 1.75 (1 RU) H x 19.00 W x 22 D inches
• Weight:
2.1.3

Temperature Range

• Operating:
• Non-operating (Storage):
2.1.4

Humidity (Non-condensing)

• Operating:
• Non-operating (Storage):
(44.45 mm H x 482.6 mm W x 558.8 mm D)
25 lbs (11.34 kg) Maximum
32° to 122° F (0° to 50° C)
-58° to 160 F° (-50° to 71° C)
0 to 95% Relative maximum
99% maximum
2–1
