LBC-4000 L-Band Up/Down Converter System
Serial Interface Operation

8.3.22 MUT (Mute State)

Command or Query. Use "MUT" to mute or unmute the specified module.
Controller-to-Target Arguments for
Instruction Code and Qualifier Command or
Response to
Command Query
MUT_ MUT_y_

8.3.23 ONL (Online State)

Query only. Use "ONL" to return which converter (slot) is ONLINE.
Controller-to-Target Arguments for
Instruction Code and Qualifier Command or
Response to
Command Query
N/A ONL_ 1 byte,
alphabetic

8.3.24 PNM (Retrieve Part Number)

Query only. Returns the factory-assigned Comtech EF Data part number for the
Unit, Conv A, or Conv B.
Controller-to-Target Arguments for
Instruction Code and Qualifier Command or
Response to
Command Query
N/A PNM_y_ 1 byte,
alphabetic
Query Examples:
Note: This number is the DOTCODE at the time the part was manufactured. The
DOTCODE may be up to 96 printable ASCII characters long.
Description of Arguments
Query
5 bytes, Set or return in the form MUT_y_xxx where:
alphabetic y=A (Conv A) or B (Conv B)
xxx=ON (mute) or OFF (unmute)
Description of Arguments
Query
Return in the form ONL_y where:
y=A (Conv A) or B (Conv B)
Description of Arguments
Query
Return in the form PNM_y_ where:
y=U (Unit), A (Conv A) or B (Conv B)
<0001/PNM_U_{cr} (Returns the Unit part number)
<0001/PNM_A_{cr} (Returns the Conv A part number)
<0001/PNM_B_{cr} (Returns the Conv B part number)
8–17
MN/LBC4000.IOM
Revision 5
Target-to-Controller
Response
Command Query
MUT_ MUT_y_xxx
Target-to-Controller
Response
Command Query
N/A ONL_y
Target-to-Controller
Response
Command Query
N/A PNM_y_x..x
