Chapter 6. FRONT PANEL
OPERATION
6.1 Front Panel Overview
You may fully control and monitor the LBC-4000 L-Band Up/Down Converter
System from the front panel (Figure 6-1).
Figure 6-1. Front Panel View
6.1.1
Power Up the LBC-4000
Figure 6-2. Available Power Switch
For units as equipped, a prime power switch is mounted behind the front panel.
To access the switch, loosen the three front panel thumb screws, slide the front
panel out from the chassis, and then drop down the panel.
