Appendix A. UP/DOWN CONVERTER IDU
MODULE REMOVAL/RE-INSTALLATION
A.1 Overview
This appendix illustrates the procedure required to remove and re-install an
IDU module for the LBC-4000 Up/Down Converter System into any
LBC-4000 chassis (Figure A-1 shows a legacy serial-only chassis with the
top cover removed for clarity). This procedure is typical for removing or
installing a module into the LBC-4000's applicable Conv A or Conv B bay.
While Figure A-1 shows the legacy chassis (LBC-4000 L-Band
Up/Down Converter System without Ethernet), the
procedures in this appendix apply identically to the
Ethernet-based LBC-4000.
Figure A-1. LBC-4000 Chassis – IDU Module Bays
A–1
