LBC-4000 L-Band Up/Down Converter System
Ethernet Interface Operation
o OID: 1.3.6.1.4.1.6247
o Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).
comtechEFData(6247)
o Module: ComtechEFData

7.2.1.2 LBC-4000 Common MIB File

• FW-0020542x.mib
• MIB file consists of all of the OID's for management of the unit functions.

7.2.1.3 LBC-4000 Traps MIB File

• FW-0020543x.mib
• Trap MIB file provides SNMPv1 traps common for the unit.

7.2.2 SNMP Community Strings

CAUTION
In SNMP v1/v2, the SNMP Community String is sent unencrypted in the
SNMP packets. Caution must be taken by the network administrator to
ensure that SNMP packets travel only over a secure and private network
if security is a concern.
For correct SNMP operation, the converter MIB files must be used with
the associated version of the unit M&C. See the LBC-4000 FW Release
Notes for information on the required FW/SW compatibility.
The LBC-4000 uses Community Strings as a password scheme that provides
authentication before gaining access to the router agent's MIBs. They are used
to authenticate users and determine access privileges to the SNMP agent. The
LBC-4000 defines three Community Strings for SNMP access:
• Read Community
• Write Community
• Trap Community
Type the SNMP Community String into the user-supplied MIB Browser or
Network Node Management software.
default = public
default = private
default = comtech
