8.3.30 RET_y_ (Retrieve Module Type)

Query only. Use "RET" with an argument to return the operating frequency and
function (i.e., up/down) of the selected module.
Controller-to-Target Arguments for
Instruction Code and Qualifier Command or
Response to
Command Query
N/A RET_y_ 12 bytes,
alphanumeric
Query Examples:

8.3.31 RMS (Retrieve Maintenance Status)

Query only. Use "RMS" to return the maintenance status of the unit.
Controller-to-Target Arguments for
Instruction Code and Qualifier Command or
Response to
Command Query
N/A RMS_ 203 bytes,
alphanumeric
Description of Arguments
Query
Query, when used with argument y, where:
y=A (Conv A) or B (Conv B)
returns a string in the form RET_y_xxx_ZZ where:
xxx=Frequency of selected module (070 or 140)
ZZ=UL (Uplink) or DL (Downlink)
<0001/RET_A_{cr}
>0001/RET_A_140_DL{cr}{lf}
<0001/RET_B_{CR}
>0001/RET_B_070_UL{cr}{lf}
Description of Arguments
Query
Returns detailed maintenance status for the unit:
12VT1=xxx.x{cr}
08VT1=xxx.x{cr}
05VT1=xxx.x{cr}
12VT2=xxx.x{cr}
08VT2=xxx.x{cr}
05VT2=xxx.x{cr}
VTREF=xxx.x{cr}
IFLOA=xxx.x{cr}
RFLOA=xxx.x{cr}
PIN_A=xxx.x{cr}.
POUTA=xxx.x{cr}
TEMPA=xxx.x{cr}
IFLOB=xxx.x{cr}
RFLOB=xxx.x{cr}
PIN_B=xxx.x{cr}
POUTB=xxx.x{cr}
TEMPB=xxx.x{cr}
8–20
Command
N/A
12VDC Supply #1 in volts
8VDC Supply #1 in volts
5VDC Supply #1 in volts
12VDC Supply #2 in volts
8VDC Supply #2 in volts
5VDC Supply #2 in volts
Ref Osc tuning in volts
Conv A IFLO tuning in volts
Conv A RFLO tuning in volts
Conv A Input power in dBm
Conv A Output power in dBm
Conv A temperature in deg C
Conv B IFLO turning in volts
Conv B RFLO tuning in volts
Conv B Input power in dBm
Conv B Output power in dBm
Conv B temperature in deg C
MN/LBC4000.IOM
Revision 5
Target-to-Controller
Response
Query
RET_y_x...Z
Target-to-Controller
Response
Command Query
N/A RMS_x...x
