1.3 Converter Features

1.3.1

Physical Description

The LBC-4000 features a 1RU-high (1.75") 19-inch wide chassis that is designed
for rack mounting into a standard 19-inch (48.26 cm) equipment rack. The unit
may also be mounted into the rack using the provided slide mechanisms to allow
service without removal from the rack. The unit may be freestanding if desired.
The LBC-4000 drop-down front panel provides access to the ON/OFF switch and
installation bays for two Up Converter modules, two Down Converter modules,
or one of each. All operator controls, indicators and displays are located on the
LBC-4000 front panel. External interface connectors, including those intended for
Ethernet or Serial Remote Monitor and Control (M&C), are located on the
LBC-4000 rear panel.
For:
Rack installation and
•
mounting instructions
• Cabling Connections
• Firmware Updating
Instructions
Local control operating
•
instructions and procedures
Remote control operating
•
instructions and procedures
Maintenance procedures
•
Redundant system operating
•
instructions and procedures
See:
Chapter 3. INSTALLATION
STARTUP
Chapter 4. REAR PANEL
CONNECTORS
Chapter 5. FIRMWARE UPDATE
Chapter 6. FRONT PANEL
OPERATION
Chapter 7. ETHERNET INTERFACE
OPERATION and
Chapter 8. SERIAL INTERFACE
OPERATION
Appendix A. UP/DOWN
CONVERTER IDU MODULE
REMOVAL / RE-INSTALLATION
Appendix B. REDUNDANCY
OPERATION
