Specifications

7.4 Mechanical Dimensions

The dimensions and order numbers of the VLT
Table 7.18.
380–415 V
50 Hz
Current
rating
[A]
10
14
22
29
34
40
55
7 7
66
82
96
133
171
204
251
304
325
381
480
Table 7.9 AHF 005: 380–415 V, 50 Hz
54
®
VLT Advanced Harmonic Filter AHF 005/AHF 010
®
Advanced Harmonic Filters AHF 005/AHF 010 can be found in Table 7.9 to
Order
number Height
[P/N] [mm (in)]
130B1229 322 (12.7)
130B1231 342 (13.5)
130B1232 454 (17.9)
130B1233 454 (17.9)
130B1238 592 (23.3)
130B1239 592 (23.3)
130B1240 592 (23.3)
130B1241 621 (24.5)
130B1247 621 (24.5)
130B1248 736 (29)
130B1249 736 (29)
130B1250 764 (30.1)
130B1251 764 (30.1)
130B1258 957 (37.7)
130B1259 957 (37.7)
130B3152 957 (37.7)
130B1260 957 (37.7)
130B1261 957 (37.7)
Danfoss A/S © 05/2019 All rights reserved.
AHF 005
Dimensions
Width Depth
[mm (in)] [mm (in)]
196 (7.7) 205 (8.1)
196 (7.7) 205 (8.1)
238 (9.4) 248 (9.8)
238 (9.4) 248 (9.8)
378 (14.9) 245 (9.6)
378 (14.9) 245 (9.6)
378 (14.9) 245 (9.6)
378 (14.9) 338 (13.3)
378 (14.9) 338 (13.3)
418 (16.5) 333 (13.1)
418 (16.5) 333 (13.1)
418 (16.5) 405 (15.9)
418 (16.5) 405 (15.9)
468 (18.4) 451 (17.8)
468 (18.4) 451 (17.8)
468 (18.4) 515 (20.3)
468 (18.4) 515 (20.3)
468 (18.4) 515 (20.3)
Weight Enclosure
[kg (lb)] type
18 (40) X1-V3 IP20 if
19 (42) X1-V3 IP20 ef
29 (64) X2-V3 IP20 ef
33 (73) X2-V3 IP20 ef
52 (115) X3-V3 IP20 if
53 (117) X3-V3 IP20 if
58 (128) X3-V3 IP20 if
76 (168) X4-V3 IP20 if
98 (216) X4-V3 IP20 ef
104 (229) X5-V3 IP20 ef
106 (234) X5-V3 IP20 ef
126 (278) X6-V3 IP20 ef
135 (298) X6-V3 IP20 ef
172 (379) X7-V3 IP20 if
206 (454) X7-V3 IP20 if
221 (487) X8-V3 IP20 if
230 (507) X8-V3 IP20 ef
272 (600) X8-V3 IP20 ef
MG80C602
