Introduction
TPF True power factor
U Nominal motor voltage
M,N
V Volt
Table 1.2 Abbreviations

1.4.2 Conventions

Numbered lists indicate procedures.
Bullet lists indicate other information and descriptions of
illustrations.
Italicized text indicates:
•
Cross-reference
•
Link
•
Footnote
•
Parameter name
•
Parameter group name
•
Parameter option
All dimensions in drawings are in mm (in).
* Indicates a default setting of a parameter.
1.4.3 Safety Symbols
The following symbols are used in this guide:
WARNING
Indicates a potentially hazardous situation that could
result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation that could
result in minor or moderate injury. It can also be used to
alert against unsafe practices.
NOTICE
Indicates important information, including situations that
can result in damage to equipment or property.

1.5 Approvals and Certifications

®
VLT Advanced Harmonic Filters AHF 005/AHF 010 are
designed in compliance with the directives described in
this section.
More approvals and certifications are available. Contact a
local Danfoss partner.
MG80C602
Design Guide

1.5.1 CE Conformity and Labeling

What is CE conformity and labeling?
The purpose of CE labeling is to avoid technical trade
obstacles within EFTA and the EU. The EU has introduced
the CE label as a simple way of showing whether a
product complies with the relevant EU directives and
standards. The CE label says nothing about the specifi-
cations or quality of the product.

1.5.2 CE Mark

Illustration 1.1 CE
The CE mark (Communauté Européenne) indicates that the
product manufacturer conforms to all applicable EU
directives. The EU directives applicable to the design and
manufacture of frequency converters are listed in Table 1.3.
NOTICE
The CE mark does not regulate the quality of the
product. Technical specifications cannot be deduced from
the CE mark.
EU Directive

Low Voltage Directive

EMC Directive
Machinery Directive
ErP Directive
ATEX Directive
RoHS Directive
Table 1.3 EU Directives Applicable to Frequency Converters
1) Machinery Directive conformance is only required for frequency
converters with an integrated safety function.
Declarations of conformity are available on request.
1.5.2.1 Low Voltage Directive
Drives must be CE-labeled in accordance with the Low
Voltage Directive of April 20, 2016. The Low Voltage
Directive applies to all electrical equipment in the 50–
1000 V AC and the 75–1500 V DC voltage ranges.
The aim of the directive is to ensure personal safety and
avoid property damage when operating electrical
equipment that is installed, maintained, and used as
intended.
Danfoss A/S © 05/2019 All rights reserved.
Version
2014/35/EU
2014/30/EU
1) 2006/42/EC
2009/125/EC
2014/34/EU
2011/65/EU
1 1
