Programming
NOTICE
[125] Follower
Marker
This option is available only with
software version 48.XX.
Normally open contact. Serves as input for
follower marker signal during marker
synchronization based on the option selected
in parameter 3-33 Sync. Mode & Start Behavior.
NOTICE
[126] Follow
Marker Inv
This option is available only with
software version 48.XX.
Normally closed contact. Serves as input for
follower marker signal during marker
synchronization based on the option selected
in parameter 3-33 Sync. Mode & Start Behavior.
[231] Power Serves as input to activate the power limit
Limit Mot. function in the motor mode. See parameter
group 4-8* Power Limit.
[232] Power Serves as input to activate the power limit
Limit Gen. function in the generating mode. See
parameter group 4-8* Power Limit.
[233] Power Serves as input to activate the power limit
Limit Both function in both the motor and the
generating mode. See parameter group 4-8*
Power Limit.
[234] Light Load Use this option to activate both light load
+ detection and evacuation.
Evacuation
5-12 Terminal 27 Digital Input
Functions are described in parameter group 5-1* Digital Inputs.
Option: Function:
[0] No operation
[1] Reset
[2] Coast inverse
[3] Coast and
reset inv
[4] Quick stop
inverse
[5] DC-brake
inverse
[6] Stop inverse
[8] Start
[9] Latched start
[10] Reversing
[11] Start reversing
[12] Enable start
forward
[13] Enable start
reverse
[14] Jog
[15] Preset
reference on
[16] Preset ref bit 0
[17] Preset ref bit 1
[18] Preset ref bit 2
MG80C602
Design Guide
5-12 Terminal 27 Digital Input
Functions are described in parameter group 5-1* Digital Inputs.
Option:
[19]
[20]
[21]
[22]
[23]
[24]
[28]
[29]
[34]
[35]
[44]
[51]
[55]
[56]
[57]
[58]
[62]
[65]
[70]
[71]
[72]
[73]
[74]
[75]
[78]
[80]
[91]
[92]
[94]
[96]
[97]
[98]
[100]
Danfoss A/S © 05/2019 All rights reserved.
Function:
Freeze
reference
Freeze output
Speed up
Speed down
Set-up select
bit 0
Set-up select
bit 1
Catch up
Slow down
Ramp bit 0
Ramp bit 1
Restart Drive
External
Interlock
DigiPot
increase
DigiPot
decrease
DigiPot clear
DigiPot Hoist
Reset Counter
A
Reset Counter
B
Mech. Brake
Feedb.
Mech. Brake
Feedb. Inv.
PID error
inverse
PID reset I
part
PID enable
MCO Specific
Reset Maint.
Word
PTC Card 1
Profidrive
OFF2
Profidrive
OFF3
Light Load
Detection
Mains Loss
Mains Loss
Inverse
Start edge
triggered
Safe Option
Reset
