Spare Parts

8.1 Selection Tables

8.1.1 Capacitor Kits for Revisions 01 and 02

The spare part capacitor kits are complete kits including cabling and accessories for replacement.
The spare part capacitor kits are supporting the following filter programs:
•
®
VLT
•
®
VLT
See chapter 8.1.2 Capacitor Kits for Revision 03 for spare part capacitor kits supporting revision 03.
NOTICE
The spare part kits are designed individually for the revision numbers 01, 02, and 03.
For spare parts for revision 01 and 02, see Table 8.1 to Table 8.5.
For spare parts for revision 03, see Table 8.6 to Table 8.10.
380–415 V, 50 Hz
Current rating
8 8
[A]
10
14
22
29
34
40
55
66
82
96
133
171
204
251
304
325
381
480
Table 8.1 Capacitor Kits, 380–415 V, 50 Hz
94
Advanced Harmonic Filter AHF 005, revisions 01 and 02.
Advanced Harmonic Filter AHF 010, revisions 01 and 02.
Order number
[P/N]
175U0134
175U0135
175U0136
175U0137
175U0138
175U0139
175U0140
175U0141
175U0142
175U0143
175U0144
175U0145
175U0146
175U0147
175U0148
175U0149
175U0150
175U0151
Danfoss A/S © 05/2019 All rights reserved.
®
VLT Advanced Harmonic Filter AHF 005/AHF 010
Valid for AHF revisions 01 and 02
Capacitor kit
Capacitor bank AHF2 DA/B 400V-50Hz-010A
Capacitor bank AHF2 DA/B 400V-50Hz-014A
Capacitor Bank AHF2 DA/B 400V-50Hz-022A
Capacitor Bank AHF2 DA/B 400V-50Hz-029A
Capacitor Bank AHF2 DA/B 400V-50Hz-034A
Capacitor Bank AHF2 DA/B 400V-50Hz-040A
Capacitor Bank AHF2 DA/B 400V-50Hz-055A
Capacitor Bank AHF2 DA/B 400V-50Hz-066A
Capacitor Bank AHF2 DA/B 400V-50Hz-082A
Capacitor Bank AHF2 DA/B 400V-50Hz-096A
Capacitor Bank AHF2 DA/B 400V-50Hz-133A
Capacitor Bank AHF2 DA/B 400V-50Hz-171A
Capacitor Bank AHF2 DA/B 400V-50Hz-204A
Capacitor Bank AHF2 DA/B 400V-50Hz-251A
Capacitor Bank AHF2 DA/B 400V-50Hz-304A
Capacitor Bank AHF2 DA/B 400V-50Hz-325A
Capacitor Bank AHF2 DA/B 400V-50Hz-381A
Capacitor Bank AHF2 DA/B 400V-50Hz-480A
Description
MG80C602
