- Page 1 Operating Instructions AHF 005/010 AHF 005/010...
-
Page 2: Table Of Contents
Typical installation in a panel or other enclosures Commissioning Commissioning Appendix: Safety and application notes for 1. General 2. Application as directed 3. Transport, Storage 4. Installation 5. Electrial Installation 6. Operation 7. Maintenance and service Index ® MG.80.B5.02 - VLT is a registered Danfoss trademark... -
Page 3: Safety
AHF 005/010 Warnings Avoid filter module damage The filter modules are to be used only with The Danfoss harmonic filter AHF 005 and Danfoss frequency converters. The usage AHF 010 contain dangerous voltages with other electrical loads is not permitted when connected to line voltages. -
Page 4: Description
440 - 480 V AC, 60 Hz • 500 - 525 V AC, 50 Hz • 690 V AC, 50 Hz The Danfoss AHF 010 and AHF 005 have the following characteristics: • Small compact housing that fits into a panel •... -
Page 5: Ordering Numbers, 380 - 415 V, 50 Hz
8602 • Please note that the matching of the typical Danfoss frequency converter and filter is pre-calculated based on 400V and assuming typical motor load (4 or 2 pole motor). VLT 5000 series is based on a max. 160 % torque application, while VLT 6000 and 8000 series are based on a max. -
Page 6: Ordering Numbers, 440 - 480 V, 60 Hz
6552 8602 • Please note that the matching of the typical Danfoss frequency converter and filter is pre-calculated based on 480V and assuming typical motor load. VLT 5000 series is based on a 160 % torque application, while VLT 6000 and 8000 series are based on 110% torque application. -
Page 7: Calculation Of The Exact Filter Size Needed
8402 130B2335 • Please note that the matching of the typical Danfoss frequency converter and filter is pre-calculated based on 500V and assuming typical motor load. VLT 5000 series is based on a 160 % torque application, while the VLT 8000 series are based on 110% torque application. -
Page 8: Specifications
Overvoltage category III according to VDE 0110 Packaging DIN 55468 for transport packaging materials Type of protection IP 20 Approvals CE: Low-Voltage Directive; UL; C-tick *climatic conditions according to class 3K3 (EN 50178 Part 6.1) ® MG.80.B5.02 - VLT is a registered Danfoss trademark... -
Page 9: Dimensions/Weight
262 Kg (578 lbs) 217 A 185 Kg (408 lbs) 289 A 309 Kg (681 lbs) 289 A 209 Kg (461 lbs) 324 A 348 Kg (767 lbs) 324 A 256 Kg (564 lbs) ® MG.80.B5.02 - VLT is a registered Danfoss trademark... - Page 10 140 kg (309 lbs) 217 A 300 kg (661 lbs) 217 A 180 kg (397 lbs) 289 A 200 kg (441 lbs) 324 A 250 kg (551 lbs) 370 A 300 kg (661 lbs) ® MG.80.B5.02 - VLT is a registered Danfoss trademark...
-
Page 11: Dimension Diagrams
AHF 005/010 Dimension diagrams Frame size B Frame size C Frame size D ® MG.80.B5.02 - VLT is a registered Danfoss trademark... - Page 12 AHF 005/010 Frame size E Frame size F Frame size G ® MG.80.B5.02 - VLT is a registered Danfoss trademark...
- Page 13 Frame size H Frame E-H only transport the filter verti- cally, i.e. use lifting hooks on both ends. Please allow an additional 30 mm of depth of the filter for the mounting feet. ® MG.80.B5.02 - VLT is a registered Danfoss trademark...
-
Page 14: Installation
370 A 3076 W 3691 W 5306 W If other heat sources (e.g. Danfoss fre- If the cooling air is polluted (dust, dirt swirl, quency converters) are installed in an en- grease, aggressive gas) the function of closure with the harmonic filter AHF 0xx, the filter module may be impeded. - Page 15 (max 30%) as well as the fact that other load normally compensates the capac- itive current. In applications where this reactive current may not be accepted, Terminals X3.1, X3.2, X3.3 and X4.1, X4, ® MG.80.B5.02 - VLT is a registered Danfoss trademark...
-
Page 16: Over Temperature Contactor
Over temperature contactor The Danfoss harmonic filter AHF 005 and AHF 010 is equipped with a galvanic isolated contactor that is closed under normal operating conditions and open if the filter is overheated. This contactor must be used to prevent damages to the filter caused by over temperature as shown in the following example. -
Page 17: Operation On Different Mains Type
Indirectly grounded star point Allowed Isolated star point Allowed The filter module has been designed completely sym- metrically for three phase operation and without refer- ence to the star point or protective earth. ® MG.80.B5.02 - VLT is a registered Danfoss trademark... -
Page 18: Typical Installation In A Panel Or Other Enclosures
Wiring between harmonic filter and frequency converter Mains supply wire of filter module Mounting plate (common star point) Potential equalisation Filter module AHF 0xx Mains connection Frequency converter Mains fuses Mains circuit breaker ® MG.80.B5.02 - VLT is a registered Danfoss trademark... -
Page 19: Commissioning
Switch on mains supply : - The filter module is ready for operation at once. Check the readiness of the frequency con- verter: - Proceed in accordance with the operating instructions of the frequency converter. ® MG.80.B5.02 - VLT is a registered Danfoss trademark... -
Page 20: Appendix: Safety And Application Notes For
/ or isolat- voltage, live parts of the filter module and power con- ing distances may not be altered. The units are equip- ® MG.80.B5.02 - VLT is a registered Danfoss trademark... -
Page 21: Maintenance And Service
During operation, all covers and doors must be closed. 7. Maintenance and service The manufacturer’s documentation must be observed. This safety information must be kept! The product-specific safety and application notes in these Operating Instructions must also be observed! ® MG.80.B5.02 - VLT is a registered Danfoss trademark... -
Page 22: Index
AHF 005/010 Index ® MG.80.B5.02 - VLT is a registered Danfoss trademark... - Page 23 175R0932 MG80B502 *MG80B502* Rev. 2006-08-28...
