Spare Parts

8.1.2 Capacitor Kits for Revision 03

The spare part capacitor kits are complete kits including cabling and accessories for replacement.
The spare parts for fans are supporting the following filter programs:
•
®
VLT Advanced Harmonic Filter AHF 005, revision 03.
•
®
VLT Advanced Harmonic Filter AHF 010, revision 03.
NOTICE
The spare part kits are designed individually for the revision numbers 01, 02, and 03.
For spare parts for revision 01 and 02, see Table 8.1 to Table 8.5.
For spare parts for revision 03, see Table 8.6 to Table 8.10.
380–415 V, 50 Hz
Current rating
[A]
10
14
22
29
34
40
55
66
82
96
133
171
204
251
304
325
381
480
Table 8.6 Capacitor Kits, 380–415 V, 50 Hz
MG80C602
Design Guide
Valid only for AHF revisions 03
Order number
[P/N]
175U1134
175U1135
175U1136
175U1137
175U1138
175U1139
175U1140
175U1141
175U1142
175U1143
175U1144
175U1145
175U1146
175U1147
175U1148
175U1149
175U1150
175U1151
Danfoss A/S © 05/2019 All rights reserved.
Capacitor kit
Description
Capacitor Bank AHF3 DA/B 400V-50Hz-010A
Capacitor Bank AHF3 DA/B 400V-50Hz-014A
Capacitor Bank AHF3 DA/B 400V-50Hz-022A
Capacitor Bank AHF3 DA/B 400V-50Hz-029A
Capacitor Bank AHF3 DA/B 400V-50Hz-034A
Capacitor Bank AHF3 DA/B 400V-50Hz-040A
Capacitor Bank AHF3 DA/B 400V-50Hz-055A
Capacitor Bank AHF3 DA/B 400V-50Hz-066A
Capacitor Bank AHF3 DA/B 400V-50Hz-082A
Capacitor Bank AHF3 DA/B 400V-50Hz-096A
Capacitor Bank AHF3 DA/B 400V-50Hz-133A
Capacitor Bank AHF3 DA/B 400V-50Hz-171A
Capacitor Bank AHF3 DA/B 400V-50Hz-204A
Capacitor Bank AHF3 DA/B 400V-50Hz-251A
Capacitor Bank AHF3 DA/B 400V-50Hz-304A
Capacitor Bank AHF3 DA/B 400V-50Hz-325A
Capacitor Bank AHF3 DA/B 400V-50Hz-381A
Capacitor Bank AHF3 DA/B 400V-50Hz-480A
8 8
