AHF005/010 Design Guide
®
MG.80.C3.02 - VLT
is a registered Danfoss trademark
3
4
4
5
5
7
7
7
7
9
9
10
12
12
13
14
15
15
15
15
16
22
23
23
23
24
24
24
24
24
24
25
25
25
27
28
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AHF005 and is the answer not in the manual?

Questions and answers

Related Manuals for Danfoss AHF005

Summary of Contents for Danfoss AHF005

  • Page 1: Table Of Contents

    6.1.1 Safety Requirements of Mechanical Installation 6.1.2 Mounting 6.1.3 Recommendations for Installation in Industrial Enclosures 6.1.4 Ventilation 6.2 Electrical Installation 6.2.1 Over Temperature Protection 6.2.2 Capacitor Disconnect 6.2.3 Wiring 6.2.4 Fuses ® MG.80.C3.02 - VLT is a registered Danfoss trademark...
  • Page 2 Contents AHF005/010 Design Guide 6.3 Mechanical Dimensions 6.3.1 Sketches 6.3.2 Physical Dimension 6.3.3 Weight 7 How to Programme the Frequency Converter 7.1.1 DC-link Compensation Disabling Index ® MG.80.C3.02 - VLT is a registered Danfoss trademark...

  • Page 3: How To Read This Design Guide

    Harmonic Filters for your VLT FC Series Drive. It describes Harmonics and how to mitigate them, provide installation instructions and guidance about how to programme the frequency converter. Danfoss technical literature is also available online at www.danfoss.com/BusinessAreas/DrivesSolutions/Documen- tations/Technical+Documentation. ® MG.80.C3.02 - VLT...

  • Page 4: Safety And Conformity

    Total Harmonic Distortion Total Harmonic Current Distortior THiD Total Harmonic Voltage Distortior THvD True Power Factor Volts The maximum output current. VLT,MAX The rated output current VLT,N supplied by the frequency converter. ® MG.80.C3.02 - VLT is a registered Danfoss trademark...

  • Page 5: Ce Conformity And Labelling

    50 - 1000 V AC and the 75 - 1500 V DC voltage ranges. Danfoss CE-labels in accordance with the directive and issues a declaration of conformity upon request.
  • Page 6 Systems where filters are installed, if applicable, have to be equipped with additional monitoring and protective devices according to the valid safety regulations e.g. law on technical tools, regulations for the prevention of accidents, etc. ® MG.80.C3.02 - VLT is a registered Danfoss trademark...

  • Page 7: Introduction To Harmonics And Mitigation

    6-pulse rectifier on a three phase supply. A non-sinusoidal waveform can be decomposed in a sum of sinusoidal waveforms with periods equal to integer multiples of the fundamental waveform. ∑ × ω See following illustrations. ® MG.80.C3.02 - VLT is a registered Danfoss trademark...
  • Page 8 Another term often encountered in literature is the partial weighted harmonic distortion (PWHD). PWHD represents a weighted harmonic distortion that contains only the harmon- ics between the 14th and the 40th, as shown in the following definition: ® MG.80.C3.02 - VLT is a registered Danfoss trademark...

  • Page 9: The Effect Of Harmonics In A Power Distribution System

    ) and the rated apparent power of the load (S • IEEE 519 S ce R sce • S equ G5/4 S sc S equ × I equ where Z supply ® MG.80.C3.02 - VLT is a registered Danfoss trademark...

  • Page 10: Harmonic Mitigation

    PCC and I is the maximum demand load current. The limits are given for individual harmonics up to the 35th and total demand distortion (TDD). ® MG.80.C3.02 - VLT is a registered Danfoss trademark...
  • Page 11 Thus the active solution can mitigate the real-time harmonic disturbances, which makes these solutions very effective at any load profile. To read more about the Danfoss active solutions Low Harmon- ic Drive (LHD) or Active Filters (AAF) please see MG.34.Ox.yy and MG.90.Vx.yy.

  • Page 12: Introduction To Advanced Harmonic Filters

    AHFs are available in two variants for two performance levels: approximately 14 %, compared to 10 % at the nominal load of AHF005 with 5 % THiD (total current harmonic distortion) and 34 A. On the other hand, the total harmonic current is only AHF010 with 10 % THiD.

  • Page 13: Power Factor

    20 and 25 %). The power factor increases with the load. Because of the higher value of the main inductor L0 Illustration 4.1: AHF005 in the AHF005, the power factor is slightly higher than in the AHF010. Following graphs show typical values for the true power factor on AHF010 and AHF005.

  • Page 14: Capacitor Disconnect

    For details about the performance positioning of the various harmonic mitigation solutions offered by Danfoss, please consult the relevant harmonic mitigation literature. ®...

  • Page 15: Selection Of Advanced Harmonic Filter

    AHF must be sized according to the sum of the calculated mains input currents. NOTE If the AHF is sized for a specific load and the motor is changed, the current must be recalculated to avoid overloading the AHF. ® MG.80.C3.02 - VLT is a registered Danfoss trademark...

  • Page 16: Electrical Data

    Selection of Advanced Harmo... AHF005/010 Design Guide 5.2 Electrical Data 380 V - 415 V, 50 Hz ® MG.80.C3.02 - VLT is a registered Danfoss trademark...
  • Page 17 Selection of Advanced Harmo... AHF005/010 Design Guide ® MG.80.C3.02 - VLT is a registered Danfoss trademark...
  • Page 18 Selection of Advanced Harmo... AHF005/010 Design Guide 380 V - 415 V, 60 Hz ® MG.80.C3.02 - VLT is a registered Danfoss trademark...
  • Page 19 Selection of Advanced Harmo... AHF005/010 Design Guide ® MG.80.C3.02 - VLT is a registered Danfoss trademark...
  • Page 20 Selection of Advanced Harmo... AHF005/010 Design Guide 440 V - 480 V, 60 Hz ® MG.80.C3.02 - VLT is a registered Danfoss trademark...
  • Page 21 Selection of Advanced Harmo... AHF005/010 Design Guide ® MG.80.C3.02 - VLT is a registered Danfoss trademark...

  • Page 22: Accessories

    Enclosure type (mm) (mm) (mm) (mm) (mm) 329.5 344.5 215.5 433.5 448.5 257.5 543.5 558.5 573.5 558.5 681.5 696.5 681.5 696.5 796.5 811.5 458.5 796.5 811.5 ® MG.80.C3.02 - VLT is a registered Danfoss trademark...

  • Page 23: General Specification

    5.3.2 Environmental Data The NEMA 1 cover is designed for the mounting of Danfoss contactors. Surroundings When using non Danfoss contactors, please observe the Ambient tempera- 5˚C... + 45˚C - without derating dimensions of the NEMA 1 terminal cover and ensure ture during full-scale 5˚C...

  • Page 24: How To Install

    150 mm (5.91 inches) to: 130B3284 130B3285 mains/supply wires 130B3286 motor wires of frequency converter 130B3287 X5 and X6 130B3288 X7 and X8 control- and signal wires (voltage range < 48 V) ® MG.80.C3.02 - VLT is a registered Danfoss trademark...

  • Page 25: Electrical Installation

    A of the harmonic filter to terminal 12 or If a disconnection of the capacitors is required a three-phase 13 (voltage supply digital input, 24 V) of the Danfoss frequen- contactor should be placed between terminals X3 and X4. It is cy converter and terminal B to terminal 27.
  • Page 26 Allow minimum 25 s for the capacitors to CI 61 discharge before re-connecting CI 61 CI 110 CI 110 CI 110 CI 110 CI 141 min. 50 % of the nominal load ® MG.80.C3.02 - VLT is a registered Danfoss trademark...

  • Page 27: Wiring

    25-300 mm 16-150 mm WFF 300 cable lug M16 60 WDU 95 N cable end sleeve 20 25-300 mm 16-150 mm Table 6.1: 380 - 415 V, 50 and 60 Hz ® MG.80.C3.02 - VLT is a registered Danfoss trademark...

  • Page 28: Fuses

    In applications where filters are paralleled it might be necessa- ry to install fuses in front of each filter and in front of the drive. ® MG.80.C3.02 - VLT is a registered Danfoss trademark...

  • Page 29: Mechanical Dimensions

    How to Install AHF005/010 Design Guide 6.3 Mechanical Dimensions 6.3.1 Sketches Illustration 6.1: X1 no fan ® MG.80.C3.02 - VLT is a registered Danfoss trademark...
  • Page 30 How to Install AHF005/010 Design Guide Illustration 6.2: X2 internal fan ® MG.80.C3.02 - VLT is a registered Danfoss trademark...
  • Page 31 How to Install AHF005/010 Design Guide Illustration 6.3: X2 external fan ® MG.80.C3.02 - VLT is a registered Danfoss trademark...
  • Page 32 How to Install AHF005/010 Design Guide Illustration 6.4: X3 internal fan ® MG.80.C3.02 - VLT is a registered Danfoss trademark...
  • Page 33 How to Install AHF005/010 Design Guide Illustration 6.5: X4 internal fan ® MG.80.C3.02 - VLT is a registered Danfoss trademark...
  • Page 34 How to Install AHF005/010 Design Guide Illustration 6.6: X5 internal fan ® MG.80.C3.02 - VLT is a registered Danfoss trademark...
  • Page 35 How to Install AHF005/010 Design Guide Illustration 6.7: X6 internal fan ® MG.80.C3.02 - VLT is a registered Danfoss trademark...
  • Page 36 How to Install AHF005/010 Design Guide Illustration 6.8: X6 external fan ® MG.80.C3.02 - VLT is a registered Danfoss trademark...
  • Page 37 How to Install AHF005/010 Design Guide Illustration 6.9: X7 internal fan ® MG.80.C3.02 - VLT is a registered Danfoss trademark...
  • Page 38 How to Install AHF005/010 Design Guide Illustration 6.10: X7 external fan ® MG.80.C3.02 - VLT is a registered Danfoss trademark...
  • Page 39 How to Install AHF005/010 Design Guide Illustration 6.11: X8 internal fan ® MG.80.C3.02 - VLT is a registered Danfoss trademark...
  • Page 40 How to Install AHF005/010 Design Guide Illustration 6.12: X8 external fan ® MG.80.C3.02 - VLT is a registered Danfoss trademark...

  • Page 41: Physical Dimension

    How to Install AHF005/010 Design Guide 6.3.2 Physical Dimension AHF010 380 - 415 V, 60 Hz AHF005 380 - 415 V, 60 Hz Current weight weight weight weight rating frame IP20 IP00 frame IP20 IP00 Enclosure Dimensions in mm size...

  • Page 42: How To Programme The Frequency Converter

    In some cases this very dynamic compensation can produce resonances in the DC link and should then be disabled. Typical cases are where AHF005/010 is used on supply grids with high short circuit ratio. Fluctuations can often be recognized by increased acoustical noise and in extreme cases by unintended tripping.

  • Page 43: Index
