Danfoss AHF 010 Design Manual page 59

Specifications
440–480 V
60 Hz
Current Order
rating number
[A] [P/N]
10 130B1482
14 130B1483
19 130B1484
25 130B1485
31 130B1486
36 130B1487
48 130B1488
60 130B1491
73 130B1492
95 130B1493
118 130B1494
154 130B1495
183 130B1496
231 130B1497
291 130B1498
355 130B1499
380 130B3165
436 130B1751
Table 7.14 AHF 010: 440–480 V, 60 Hz
600 V
60 Hz
Current Order
rating number
[A] [P/N]
15 130B5246
20 130B5247
24 130B5248
29 130B5249
36 130B5250
50 130B5251
58 130B5252
77 130B5253
87 130B5254
109 130B5255
128 130B5256
155 130B5257
197 130B5258
240 130B5259
296 130B5260
366 –
395 –
Table 7.15 AHF 005: 600 V, 60 Hz
MG80C602
Design Guide
AHF 010
Dimensions
Height Width
[mm (in)] [mm (in)]
322 (12.7) 196 (7.7)
342 (13.5) 196 (7.7)
434 (17.1) 238 (9.4)
434 (17.1) 238 (9.4)
592 (23.3) 378 (14.9)
592 (23.3) 378 (14.9)
592 (23.3) 378 (14.9)
621 (24.5) 378 (14.9)
621 (24.5) 378 (14.9)
736 (29) 418 (16.5)
736 (29) 418 (16.5)
764 (30.1) 418 (16.5)
764 (30.1) 418 (16.5)
957 (37.7) 468 (18.4)
957 (37.7) 468 (18.4)
957 (37.7) 468 (18.4)
957 (37.7) 468 (18.4)
957 (37.7) 468 (18.4)
AHF 005
Dimensions
Height Width
[mm (in)] [mm (in)]
592 (23.3) 378 (14.9)
592 (23.3) 378 (14.9)
593 (23.4) 378 (14.9)
621 (24.5) 378 (14.9)
621 (24.5) 378 (14.9)
736 (29) 418 (16.5)
736 (29) 418 (16.5)
764 (30.1) 418 (16.5)
764 (30.1) 418 (16.5)
764 (30.1) 418 (16.5)
764 (30.1) 418 (16.5)
957 (37.7) 468 (18.4)
957 (37.7) 468 (18.4)
957 (37.7) 468 (18.4)
957 (37.7) 468 (18.4)
– –
– –
Danfoss A/S © 05/2019 All rights reserved.
Weight
Depth
[kg (lb)]
[mm (in)]
205 (8.1) 13.5 (29.8)
205 (8.1) 15.2 (33.5)
248 (9.8) 21 (47)
248 (9.8) 24 (53)
245 (9.6) 33 (73)
245 (9.6) 37 (82)
245 (9.6) 39 (86)
338 (13.3) 44 (97)
338 (13.3) 56 (123)
333 (13.1) 62 (137)
333 (13.1) 74 (164)
405 (15.9) 85 (187)
405 (15.9) 102 (225)
451 (17.8) 119 (262)
451 (17.8) 142 (313)
451 (17.8) 163 (359)
451 (17.8) 172 (379)
515 (20.3) 205 (452)
Weight
Depth
[kg (lb)]
[mm (in)]
245 (9.6) 42 (93)
245 (9.6) 50 (110)
245 (9.6) 52 (115)
338 (13.3) 75 (165)
338 (13.3) 82 (181)
333 (13.1) 96 (212)
333 (13.1) 104 (229)
405 (15.9) 130 (287)
405 (15.9) 135 (298)
405 (15.9) 168 (370)
405 (15.9) 197 (434)
451 (17.8) 220 (485)
451 (17.8) 228 (503)
515 (20.3) 260 (573)
515 (20.3) 297 (655)
– –
– –
Enclosure
type
X1-V3 IP20 if
X1-V3 IP20 ef
X2-V3 IP20 if
X2-V3 IP20 if
X3-V3 IP20 if
X3-V3 IP20 if
X3-V3 IP20 if
X4-V3 IP20 if
X4-V3 IP20 ef
X5-V3 IP20 ef
X5-V3 IP20 ef
X6-V3 IP20 if
7
X6-V3 IP20 if
X7-V3 IP20 if
X7-V3 IP20 if
X7-V3 IP20 ef
X7-V3 IP20 ef
X8-V3 IP20 ef
Enclosure
type
X3-V3 IP20 if
X3-V3 IP20 if
X3-V3 IP20 ef
X4-V3 IP20 ef
X4-V3 IP20 ef
X5-V3 IP20 ef
X5-V3 IP20 ef
X6-V3 IP20 ef
X6-V3 IP20 ef
X6-V3 IP20 ef
X6-V3 IP20 ef
X7-V3 IP20 ef
X7-V3 IP20 ef
X8-V3 IP20 ef
X8-V3 IP20 ef
–
–
57
7
