Specifications
380–415 V
60 Hz
Current
rating
[A]
10
14
22
29
34
40
55
66
82
96
133
171
7 7
204
251
304
325
381
480
Table 7.12 AHF 010: 380–415 V, 60 Hz
440–480 V
60 Hz
Current
rating
[A]
10
14
19
25
31
36
48
60
73
95
118
154
183
231
291
355
380
436
Table 7.13 AHF 005: 440–480 V, 60 Hz
56
®
VLT Advanced Harmonic Filter AHF 005/AHF 010
Order
number Height
[P/N] [mm (in)]
130B2262 322 (12.7)
130B2265 342 (13.5)
130B2268 434 (17.1)
130B2294 434 (17.1)
130B2297 592 (23.3)
130B2303 592 (23.3)
130B2445 592 (23.3)
130B2459 621 (24.5)
130B2488 621 (24.5)
130B2489 736 (29)
130B2498 736 (29)
130B2499 764 (30.1)
130B2500 764 (30.1)
130B2700 957 (37.7)
130B2819 957 (37.7)
130B3154 957 (37.7)
130B2855 957 (37.7)
130B2856 957 (37.7)
Order
number
Height
[P/N]
[mm (in)]
130B1752 322 (12.7)
130B1753 342 (13.5)
130B1754 454 (17.1)
130B1755 454 (17.1)
130B1756 592 (23.3)
130B1757 592 (23.3)
130B1758 592 (23.3)
130B1759 621 (24.5)
130B1760 621 (24.5)
130B1761 736 (29)
130B1762 736 (29)
130B1763 764 (30.1)
130B1764 764 (30.1)
130B1765 957 (37.7)
130B1766 957 (37.7)
130B1768 957 (37.7)
130B3167 957 (37.7)
130B1769 957 (37.7)
Danfoss A/S © 05/2019 All rights reserved.
AHF 010
Dimensions
Width Depth
[mm (in)] [mm (in)]
196 (7.7) 205 (8.1)
196 (7.7) 205 (8.1)
238 (9.4) 248 (9.8)
238 (9.4) 248 (9.8)
378 (14.9) 245 (9.6)
378 (14.9) 245 (9.6)
378 (14.9) 245 (9.6)
378 (14.9) 338 (13.3)
378 (14.9) 338 (13.3)
418 (16.5) 333 (13.1)
418 (16.5) 333 (13.1)
418 (16.5) 405 (15.9)
418 (16.5) 405 (15.9)
468 (18.4) 451 (17.8)
468 (18.4) 451 (17.8)
468 (18.4) 451 (17.8)
468 (18.4) 451 (17.8)
468 (18.4) 515 (20.3)
AHF 005
Dimensions
Width Depth
[mm (in)] [mm (in)]
196 (7.7) 205 (8.1)
196 (7.7) 205 (8.1)
238 (9.4) 248 (9.8)
238 (9.4) 248 (9.8)
378 (14.9) 245 (9.6)
378 (14.9) 245 (9.6)
378 (14.9) 245 (9.6)
378 (14.9) 338 (13.3)
378 (14.9) 338 (13.3)
418 (16.5) 333 (13.1)
418 (16.5) 333 (13.1)
418 (16.5) 405 (15.9)
418 (16.5) 405 (15.9)
468 (18.4) 451 (17.8)
468 (18.4) 515 (20.3)
468 (18.4) 515 (20.3)
468 (18.4) 515 (20.3)
468 (18.4) 515 (20.3)
Weight Enclosure
[kg (lb)] type
13.5 (29.8) X1-V3 IP20 if
15.2 (33.5) X1-V3 IP20 ef
21 (47) X2-V3 IP20 if
24 (53) X2-V3 IP20 if
33 (73) X3-V3 IP20 if
37 (82) X3-V3 IP20 if
39 (86) X3-V3 IP20 if
44 (97) X4-V3 IP20 if
56 (123) X4-V3 IP20 ef
62 (137) X5-V3 IP20 ef
74 (164) X5-V3 IP20 ef
85 (187) X6-V3 IP20 if
102 (225) X6-V3 IP20 if
119 (262) X7-V3 IP20 if
142 (313) X7-V3 IP20 if
163 (359) X7-V3 IP20 ef
172 (380) X7-V3 IP20 ef
205 (452) X8-V3 IP20 ef
Weight Enclosure
[kg (lb)] type
18 (40) X1-V3 IP20 if
19 (42) X1-V3 IP20 ef
29 (64) X2-V3 IP20 ef
33 (73) X2-V3 IP20 ef
52 (115) X3-V3 IP20 if
53 (117) X3-V3 IP20 if
58 (128) X3-V3 IP20 if
76 (168) X4-V3 IP20 if
98 (216) X4-V3 IP20 ef
104 (229) X5-V3 IP20 ef
106 (234) X5-V3 IP20 ef
126 (278) X6-V3 IP20 ef
135 (298) X6-V3 IP20 ef
172 (379) X7-V3 IP20 if
221 (487) X8-V3 IP20 if
230 (507) X8-V3 IP20 ef
265 (584) X8-V3 IP20 ef
272 (600) X8-V3 IP20 ef
