6.3 Mechanical Dimensions

6.3.1 Sketches

F1
F2
Illustration 6.2 X1 No Fan
AHF005/010 Design Guide
246 mm[9.69 In]
276 mm[10.87 In]
295 mm[11.67 In]
332,11 mm[13.08 In]
®
MG.80.C4.02 - VLT
is a registered Danfoss trademark
190 mm[7.48 In]
6
37
6
