Danfoss AHF 010 Design Manual page 94

Specifications
Filter current rating
[A]
15
20
24
29
36
50
58
77
87
109
128
155
197
240
296
7 7
366
395
Table 7.26 600 V, 60 Hz
1) Specified type is a UL requirement.
Filter current rating
[A]
15
20
24
29
36
50
58
77
87
109
128
155
197
240
296
366
395
Table 7.27 500–690 V, 50 Hz
In applications where filters are paralleled, it might be necessary to install fuses in front of each filter and in front of the
frequency converter.
92
®
VLT Advanced Harmonic Filter AHF 005/AHF 010
Maximum fuse size
[A]
35
35
50
50
60
80
100
125
150
200
250
300
350
400
500
600
600
Maximum fuse size
[A]
35
35
50
50
63
80
125
160
250
250
250
315
350
400
500
630
630
Danfoss A/S © 05/2019 All rights reserved.
1)
Fuses
(type)
Class J, 600 V AC, rated circuit breaker capacity 100 kA
Class J, 600 V AC, rated circuit breaker capacity 100 kA
Class J, 600 V AC, rated circuit breaker capacity 100 kA
Class J, 600 V AC, rated circuit breaker capacity 100 kA
Class J, 600 V AC, rated circuit breaker capacity 100 kA
Class J, 600 V AC, rated circuit breaker capacity 100 kA
Class J, 600 V AC, rated circuit breaker capacity 100 kA
Class J, 600 V AC, rated circuit breaker capacity 100 kA
Class J, 600 V AC, rated circuit breaker capacity 100 kA
Class J, 600 V AC, rated circuit breaker capacity 100 kA
Class J, 600 V AC, rated circuit breaker capacity 100 kA
Class J, 600 V AC, rated circuit breaker capacity 100 kA
Class J, 600 V AC, rated circuit breaker capacity 100 kA
Class J, 600 V AC, rated circuit breaker capacity 100 kA
Class J, 600 V AC, rated circuit breaker capacity 100 kA
Class J, 600 V AC, rated circuit breaker capacity 100 kA
Class J, 600 V AC, rated circuit breaker capacity 100 kA
Fuses
(type)
gRL 690 V AC
gRL 690 V AC
gRL 690 V AC
gRL 690 V AC
gRL 690 V AC
gRL 690 V AC
gRL 690 V AC
gRL 690 V AC
gRL 690 V AC
gRL 690 V AC
gRL 690 V AC
gRL 690 V AC
gRL 690 V AC
gRL 690 V AC
gRL 690 V AC
gRL 690 V AC
gRL 690 V AC
MG80C602
