Programming
[110] Start
Homing
[111] Activate
Touch
[112] Relative
6 6 Position
[113] Enable
Reference
[114] Sync. to
Pos. Mode
[115] Home
Sensor
[116] Home
Sensor Inv.
44
®
VLT
NOTICE
This option is available only with
software version 48.XX.
Starts the homing function selected in
parameter 17-80 Homing Function. Must
remain high until homing is done, otherwise
homing is aborted.
NOTICE
This option is available only with
software version 48.XX.
Activates the monitoring of the touch sensor
input.
NOTICE
This option is available only with
software version 48.XX.
This option selects between absolute and
relative positioning. The option is valid for
the next positioning command.
NOTICE
This option is available only with
software version 48.XX.
Positioning mode: The frequency converter
activates the selected positioning type and
target and starts the motion towards the new
target. The motion starts either immediately
or when active positioning is completed,
depending on settings of
parameter 17-90 Absolute Position Mode and
parameter 17-91 Relative Position Mode.
Synchronization mode: High signal locks the
actual follower position to the actual master
position. The follower starts and catches up
with the master. Low signal stops the
synchronization and the follower makes a
controlled stop.
NOTICE
This option is available only with
software version 48.XX.
Select positioning in synchronization mode.
NOTICE
This option is available only with
software version 48.XX.
Normally open contact for defining the home
position. The function is defined in
parameter 17-80 Homing Function.
NOTICE
This option is available only with
software version 48.XX.
Normally closed contact for defining the
home position. The function is defined in
parameter 17-80 Homing Function.
Danfoss A/S © 05/2019 All rights reserved.
Advanced Harmonic Filter AHF 005/AHF 010
[117] Touch
Sensor
[118] Touch
Sensor Inv
[119] Speed
mode
[122] Position Vir.
Master.
[123] Master
Marker
[124] Master
Marker Inv.
NOTICE
This option is available only with
software version 48.XX.
Normally open contact. Serves as a reference
for touch probe positioning.
NOTICE
This option is available only with
software version 48.XX.
Normally closed contact. Serves as a
reference for touch probe positioning.
NOTICE
This option is available only with
software version 48.XX.
Select the speed mode when [9] Positioning
or [10] Synchronization is selected in
parameter 1-00 Configuration Mode. Speed
reference is set by reference resource 1 or
fieldbus REF1 relative to
parameter 3-03 Maximum Reference.
NOTICE
This option is available only with
software version 48.XX.
Activates position controlled virtual master
when [10] Synchronization is selected in
parameter 1-00 Configuration Mode.
When the option is selected, the following
occurs:
•
Target position is set by Fieldbus
Pos Ref or preset target is as
defined in parameter 3-20 Preset
Target.
•
Speed is set relative to
parameter 3-27 Virtual Master Max
Ref by the source selected in
parameter 3-15 Reference Resource 1
or fieldbus REF1.
•
Acceleration and deceleration is set
as defined in parameter group 3-6*
Ramp 3.
NOTICE
This option is available only with
software version 48.XX.
Normally open contact. Serves as input for
master marker signal during marker synchro-
nization based on the option selected in
parameter 3-33 Sync. Mode & Start Behavior.
NOTICE
This option is available only with
software version 48.XX.
Normally closed contact. Activates master
marker signal for marker synchronization
based on the option selected in
parameter 3-33 Sync. Mode & Start Behavior.
