Programming

6 Programming

6.1 Parameter Descriptions

The parameters in this section are limited to the
parameters required for operating the VLT
Harmonic Filter AHF 005/AHF 010. For reference to other
parameters, refer to the frequency converter programming
guide.
5-00 Digital I/O Mode
Digital inputs and programmed digital outputs are pre-
programmable for operation either in PNP or NPN systems.
Option: Function:
NOTICE
Perform a power cycle to
activate the parameter once it
has been changed.
[0] PNP Action on positive directional pulses
*
(↕). PNP systems are pulled down
to GND.
[1] NPN Action on negative directional
pulses (↕). NPN systems are pulled
up to +24 V, internally in the
frequency converter.
5-01 Terminal 27 Mode
Option: Function:
NOTICE
This parameter cannot be
adjusted while the motor is
running.
[0] Input Defines terminal 27 as a digital
*
input.
[1] Output Defines terminal 27 as a digital
output.
5-02 Terminal 29 Mode
Option: Function:
NOTICE
This parameter is available for
FC 302 only.
[0] Input Defines terminal 29 as a digital
*
input.
[1] Output Defines terminal 29 as a digital
output.
MG80C602
Design Guide
6.1.1 5-1* Digital Inputs
The digital inputs are used for selecting various functions
®
Advanced
in the frequency converter. Table 6.2 shows which functions
can be assigned to digital inputs.
Functions in group 1 have higher priority than functions in
group 2.
Group 1
Group 2
Table 6.1 Function Groups
Digital input function
No operation
Reset
Coast inverse
Coast and reset inverse
Quick stop inverse
DC brake inverse
Stop inverse
Start
Latched start
Reversing
Start reversing
Enable start forward
Enable start reverse
Jog
Preset reference on
Preset ref bit 0
Preset ref bit 1
Preset ref bit 2
Freeze reference
Freeze output
Speed up
Speed down
Set-up select bit 0
Set-up select bit 1
Precise stop inverse
Precise start, stop
Catch up
Slow down
Counter input
Pulse input edge
triggered
Pulse input time based
Ramp bit 0
Ramp bit 1
Danfoss A/S © 05/2019 All rights reserved.
Reset, coast stop, reset, and coast stop, quick stop,
DC brake, stop, and the [Off] key.
Start, latched start, reversing, start reversing, jog,
and freeze output.
Select Terminal
[0] All, terminal 32, 33
[1] All
[2] All, terminal 27
[3] All
[4] All
[5] All
[6] All
[8] All, terminal 18
[9] All
[10] All, terminal 19
[11] All
[12] All
[13] All
[14] All, terminal 29
[15] All
[16] All
[17] All
[18] All
[19] All
[20] All
[21] All
[22] All
[23] All
[24] All
[26] 18, 19
[27] 18, 19
[28] All
[29] All
[30] 29, 33
[31] 29, 33
[32] 29, 33
[34] All
[35] All
