Selection of Advanced Harmo...
Drive values
Power rating
T6 T7
[kW] 1)
2) 2)
[hp] [hp]
11 15 10
15 20 15
18.5 25 20
22 30 25
30 40 30
37 50 40
45 60 50
55 75 60
75 100 75
90 125 100
110 – 125
132 – 150
160 – 200
200 – 250
250 – 300
315 – 350
355 – 400
400 – 400
500 – 500
560 – 550
630 – 650
710 – 750
800 – 950
900 – 1050
1000 – 1150
Table 5.6 Frequency Converters with Voltage Classes T6 and T7, Operating at 600 V, 60 Hz
1) The power ratings in selection table are the actual operating power and not necessarily the type code power rating.
Changing operating conditions between HO and NO changes the actual operating conditions and the filter selection must reflect actual operating
conditions.
2) Typical hp shaft output at 575 V.
MG80C602
Design Guide
Selection table, 600 V, 60 Hz
Input current Current rating
551–600 V at 600 V
T6 T7 AHF 005 AHF 010
[A] [A] [A]
16 15 15
20 19.5 20
24 24 24
31 29 29
37 36 36
47 49 50
56 59 58
75 74 77
91 85 87
119 106 109
– 124 128
– 151 155
– 189 197
– 234 240
– 286 296
– 339 394
– 366 394
– 395 394
– 482 480
– 549 592
– 613 720
– 711 720
– 828 888
– 920 960
– 1032 1184 1098
Danfoss A/S © 05/2019 All rights reserved.
AHF values
Order numbers
AHF 005 AHF 010
[A] IP20 IP20
15 130B5246 130B5212
20 130B5247 130B5213
24 130B5248 130B5214
29 130B5249 130B5215
36 130B5250 130B5216
50 130B5251 130B5217
58 130B5252 130B5218
77 130B5253 130B5219
87 130B5254 130B5220
109 130B5255 130B5221
128 130B5256 130B5222
155 130B5257 130B5223
197 130B5258 130B5224
240 130B5259 130B5225
296 130B5260 130B5226
366 2 x 130B5258 130B5227
366 2 x 130B5258 130B5227
395 2 x 130B5258 130B5228
480 2 x 130B5259 2 x 130B5225
592 2 x 130B5260 2 x 130B5226
732 3 x 130B5259 2 x 130B5227
732 3 x 130B5259 2 x 130B5227
888 3 x 130B5260 3 x 139B5226
960 4 x 130B5259 3 x 130B5227
4 x 130B5260 3 x 130B5227
Enclosure type
AHF 005 AHF 010
IP20 IP20
X3-V3 IP20 if X3-V3 IP20 if
X3-V3 IP20 if X3-V3 IP20 if
X3-V3 IP20 ef X3-V3 IP20 ef
X4-V3 IP20 ef X4-V3 IP20 ef
X4-V3 IP20 ef X4-V3 IP20 ef
X5-V3 IP20 ef X5-V3 IP20 ef
X5-V3 IP20 ef X5-V3 IP20 ef
X6-V3 IP20 ef X6-V3 IP20 ef
X6-V3 IP20 ef X6-V3 IP20 ef
X6-V3 IP20 ef X6-V3 IP20 ef
X6-V3 IP20 ef X6-V3 IP20 ef
X7-V3 IP20 ef X7-V3 IP20 ef
X7-V3 IP20 ef X7-V3 IP20 ef
X8-V3 IP20 ef X7-V3 IP20 ef
X8-V3 IP20 ef X8-V3 IP20 ef
X8-V3 IP20 ef
See individual
X8-V3 IP20 ef
filters
X8-V3 IP20 ef
See individual filters
