Danfoss AHF 010 Design Manual page 101

Spare Parts
600 V, 60 Hz
Current rating
[A]
15
20
24
29
36
50
58
77
87
109
128
155
197
240
296
366
395
Table 8.9 Capacitor Kits, 600 V, 60 Hz
500–690 V, 50 Hz
Current rating
[A]
15
20
24
29
36
50
58
77
87
109
128
155
197
240
296
366
395
Table 8.10 Capacitor Kits, 500–690 V, 50 Hz
MG80C602
Design Guide
Valid only for AHF revisions 03
Order number
[P/N]
175U1205
175U1206
175U1207
175U1208
175U1209
175U1211
175U1212
175U1213
175U1214
175U1215
175U1217
175U1218
175U1219
175U1245
175U1254
175U1255
175U1256
Valid only for AHF revisions 03
Order number
[P/N]
175U1173
175U1174
175U1175
175U1176
175U1177
175U1178
175U1180
175U1190
175U1193
175U1195
175U1196
175U1197
175U1198
175U1199
175U1201
175U1202
175U1203
Danfoss A/S © 05/2019 All rights reserved.
Capacitor kit
Description
Capacitor Bank AHF3 DA/B 600V-60Hz-015A
Capacitor Bank AHF3 DA/B 600V-60Hz-020A
Capacitor Bank AHF3 DA/B 600V-60Hz-024A
Capacitor Bank AHF3 DA/B 600V-60Hz-029A
Capacitor Bank AHF3 DA/B 600V-60Hz-036A
Capacitor Bank AHF3 DA/B 600V-60Hz-050A
Capacitor Bank AHF3 DA/B 600V-60Hz-058A
Capacitor Bank AHF3 DA/B 600V-60Hz-077A
Capacitor Bank AHF3 DA/B 600V-60Hz-087A
Capacitor Bank AHF3 DA/B 600V-60Hz-109A
Capacitor Bank AHF3 DA/B 600V-60Hz-128A
Capacitor Bank AHF3 DA/B 600V-60Hz-155A
Capacitor Bank AHF3 DA/B 600V-60Hz-197A
Capacitor Bank AHF3 DA/B 600V-60Hz-240A
Capacitor Bank AHF3 DA/B 600V-60Hz-296A
Capacitor Bank AHF3 DA 600V-60Hz-366A
Capacitor Bank AHF3 DA 600V-60Hz-395A
Capacitor kit
Description
Capacitor Bank AHF3 DA/B 690V-50Hz-015A
Capacitor Bank AHF3 DA/B 690V-50Hz-020A
Capacitor Bank AHF3 DA/B 690V-50Hz-024A
Capacitor Bank AHF3 DA/B 690V-50Hz-029A
Capacitor Bank AHF3 DA/B 690V-50Hz-036A
Capacitor Bank AHF3 DA/B 690V-50Hz-050A
Capacitor Bank AHF3 DA/B 690V-50Hz-058A
Capacitor Bank AHF3 DA/B 690V-50Hz-077A
Capacitor Bank AHF3 DA/B 690V-50Hz-087A
Capacitor Bank AHF3 DA/B 690V-50Hz-109A
Capacitor Bank AHF3 DA/B 690V-50Hz-128A
Capacitor Bank AHF3 DA/B 690V-50Hz-155A
Capacitor Bank AHF3 DA/B 690V-50Hz-197A
Capacitor Bank AHF3 DA/B 690V-50Hz-240A
Capacitor Bank AHF3 DA/B 690V-50Hz-296A
Capacitor Bank AHF3 DA 690V-50Hz-366A
Capacitor Bank AHF3 DA 690V-50Hz-395A
