Danfoss AHF 010 Design Manual page 31

Selection of Advanced Harmo...
Drive values
Input
Power rating
current
1) 380–440 V
[kW]
[A]
0.37 1.2
0.55 1.6
0.75 2.2
1.1 2.7
1.5 3.7
2.2 5.0
3.0 6.5
4.0 9.0
5.5 11.7
7.5 14.4
11 22
15 29
18.5 34
22 40
30 55
37 66
45 82
55 96
75 133
90 171
110 204
132 251
160 304
– –
200 381
250 463
315 590
355 647
400 684
450 779
500 857
560 964
630 1090
710 1227
800 1422
1000 1675
Table 5.4 Frequency Converters with Voltage Classes T4 and T5, Operating at 380–415 V, 60 Hz
1) The power ratings in selection table are the actual operating power and not necessarily the type code power rating.
Changing operating conditions between HO and NO changes the actual operating conditions and the filter selection must reflect actual operating
conditions.
2) Typical hp shaft output at 460 V.
3) The fan control system allows extended input voltage range as 200–415 V. The AHFs for 380–415 V/60 Hz mains operation can be operated
with 200–240 V mains supply.
4) Filters are used as paralleling for 355 kW drive.
MG80C602
Design Guide
Selection table, 380–415 V, 60 Hz
Order numbers
Current
rating
AHF 005 IP20
[A]
10 130B2857
14 130B2858
22 130B2859
29 130B2860
34 130B2861
40 130B2862
55 130B2863
66 130B2864
82 130B2865
96 130B2866
133 130B2867
171 130B2868
204 130B2869
251 130B2870
304 130B2871
325 4)
130B3156
381 130B2872
480 130B2873
608 2 x 130B2871
650 2 x 130B3156
130B2871 +
685
130B2872
762 2 x 130B2872
130B2872 +
861
130B2873
960 2 x 130B2873
1140 3 x 130B2872
2 x 130B2872 +
1240
130B2873
1440 3 x 130B2873
2 x 130B2872 +
1720
2 x 130B2873
Danfoss A/S © 05/2019 All rights reserved.
AHF values
3)
AHF 010 IP20 AHF 005 IP20
130B2262 X1-V3 IP20 if
130B2265 X1-V3 IP20 ef
130B2268 X2-V3 IP20 ef
130B2294 X2-V3 IP20 ef
130B2297 X3-V3 IP20 if
130B2303 X3-V3 IP20 if
130B2445 X3-V3 IP20 if
130B2459 X4-V3 IP20 if
130B2488 X4-V3 IP20 ef
130B2489 X5-V3 IP20 ef
130B2498 X5-V3 IP20 ef
130B2499 X6-V3 IP20 ef
130B2500 X6-V3 IP20 ef
130B2700 X7-V3 IP20 if
130B2819 X8-V3 IP20 if
4) X8-V3 IP20 ef
130B3154
130B2855 X8-V3 IP20 ef
130B2856 X8-V3 IP20 ef
2 x 130B2819
2 x 130B3154
130B2819 +
130B2855
2 x 130B2855
130B2855 +
130B2856
2 x 130B2856
3 x 130B2855
2 x 130B2855 +
130B2856
3 x 130B2856
2 x 130B2855 +
2 x 130B2856
Enclosure type
AHF 010 IP20
X1-V3 IP20 if
X1-V3 IP20 ef
X2-V3 IP20 if
X2-V3 IP20 if
X3-V3 IP20 if
X3-V3 IP20 if
X3-V3 IP20 if
X4-V3 IP20 if
X4-V3 IP20 ef
X5-V3 IP20 ef
X5-V3 IP20 ef
X6-V3 IP20 if
X6-V3 IP20 if
X7-V3 IP20 if
X7-V3 IP20 if
X7-V3 IP20 ef
X7-V3 IP20 ef
X8-V3 IP20 ef
See individual filters
29
5 5
